CSE-P EX E INTRINSICALLY SAFE ENCLOSURES
The CSE P Ex e enclosures are normally used in the chemical and petrochemical plants, off-shore platforms, refineries and any other industry where hazardous atmospheres (gas and combustible dust) are potentially present.
The CSE P Ex e enclosures range of intrinsically safe enclosures has been designed to meet the main requirements of power distribution, monitoring and signaling, and other electrical functions inside the hazardous area of the plant.
The materials used to manufacture the CSE P series have been studied to grant the maximum protection against the highly corrosive agents present in these industries:
- body and cover of glass-reinforced polyester (GRP) black coloured to provide the maximum UV protection and loaded with carbon, to eliminate the risk of ignition sources through static induced sparking resistivity.
- for special purposes there are available, on request, other colours : grey, yellow, red and light blue
- antiloosening screws on cover of stainless steel AISI 316
- gasket on cover of silicone
- internal fixing screws of stainless steel
|
product | overall dimension | internal dimensions | mounting details | fixing dimensions | weight | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | a | b | c | d | e | f | g | screw | kg | ||
| CSE 080705P | 80 | 75 | 55 | 73 | 68 | 47 | 68 | 64 | 68 | 45 | M4 | 0.2 | |
| CSE 110705P | 110 | 75 | 55 | 103 | 68 | 47 | 98 | 64 | 98 | 45 | M4 | 0.3 | |
| CSE 160705P | 160 | 75 | 55 | 153 | 68 | 47 | 148 | 64 | 98 | 45 | M4 | 0.4 | |
| CSE 190705P | 190 | 75 | 55 | 183 | 68 | 47 | 178 | 64 | 178 | 45 | M4 | 0.5 | |
| CSE 080707P | 80 | 75 | 75 | 73 | 68 | 67 | 68 | 64 | 68 | 45 | M4 | 0.4 | |
| CSE 121209P | 122 | 120 | 90 | 115 | 113 | 79 | 108 | 106 | 106 | 82 | M4 | 0.8 | |
| CSE 221209P | 220 | 120 | 90 | 211 | 111 | 79 | 206 | 106 | 204 | 82 | M4 | 1.0 | |
| CSE 161609P | 160 | 160 | 90 | 148 | 148 | 79 | 144 | 140 | 140 | 110 | M4 | 1.2 | |
| CSE 261609P | 260 | 160 | 90 | 248 | 148 | 79 | 244 | 140 | 240 | 110 | M4 | 1.7 | |
| CSE 361609P | 360 | 160 | 90 | 348 | 148 | 79 | 344 | 140 | 340 | 110 | M4 | 2.2 | |
| CSE 202512P | 200 | 250 | 120 | 188 | 238 | 109 | 185 | 232 | 180 | 200 | M4 | 2.3 | |
| CSE 252512P | 255 | 250 | 120 | 242 | 238 | 109 | 240 | 232 | 235 | 200 | M6 | 2.7 | |
| CSE 402512P | 400 | 250 | 120 | 388 | 238 | 109 | 385 | 232 | 380 | 200 | M6 | 3.7 | |
| CSE 404012P | 400 | 405 | 120 | 388 | 393 | 109 | 383 | 386 | 380 | 355 | M6 | 5.4 | |
| CSE 602512P | 600 | 250 | 120 | 588 | 238 | 109 | 585 | 232 | 580 | 200 | M6 | 5.3 | |
| CSE 252516P | 255 | 250 | 160 | 242 | 238 | 149 | 240 | 232 | 235 | 200 | M6 | 3.2 | |
| CSE 402516P | 400 | 250 | 160 | 388 | 238 | 149 | 385 | 232 | 380 | 200 | M6 | 4.6 | |
| CSE 602516P | 600 | 250 | 160 | 588 | 238 | 149 | 585 | 232 | 580 | 200 | M6 | 6.5 | |
The CSE P ex e enclosures are normally used for the following main applications:
- control stations
- emergency call units
- instrument housings
- circuit breakers
- switches and changeover switches
- lighting controls
- terminal boxes
- electrical housing
- battery container
The CSE-P ex e enclosures are available in different sizes so to create a large and modular range with different heights. The CSE-P ex e enclosures, joined together through dedicated flanges, can become a large panel, maintaining the original IP protection.
Starting height 90 mm, the CSE-P series can be equipped with operators (pilot lights, push buttons, switches, etc.) on cover.
The materials used to manufacture the CSE P series have been studied to grant the maximum protection against the highly corrosive agents present in these industries:
- body and cover of glass-reinforced polyester (GRP) black coloured to provide the maximum UV protection and loaded with carbon, to eliminate the risk of ignition sources through static induced sparking resistivity.
- for special purposes there are available, on request, other colours : grey, yellow, red and light blue
- antiloosening screws on cover of stainless steel AISI 316
- gasket on cover of silicone
- internal fixing screws of stainless steel
The CSE P ex e enclosures can be completed with the following accessories:
- internal earth continuity plate of galvanized steel, copper or brass
- internal mounting plate of galvanized steel or stainless steel
- mounting brackets in stainless steel
- internal and external earth screws of stainless steel AISI 316
- external hinges of thermoplastic material
certificate number: IECEx IMQ 15.0004X IMQ 14 ATEX 003 X TC RU C-IT.AA87.B.00509
marking:
II 2GD Ex e ia IIC T6/T5 Gb Ex tb IIIC T85/T100°C Db (terminal boxes)
II 2GD Ex d e [ia/ib] mb IIC T6/T5/T4 Gb Ex tb IIIC T85/T100/T135°C Db (control stations)
ambient temperature: –40°C +60°C
degree of protection: IP65/66
conformity: Directive ATEX 2014/34/EU TP TC 012/2011
standards: IEC-EN60079-0 IEC-EN60079-1 IEC-EN60079-7 IEC-EN60079-11 IEC-EN 60079-18 IEC-EN60079-31
ГОСТ 31610.0 ГОСТ IEC 60079-1 ГОСТ Р МЭК 60079-7 ГОСТ 31610.11 ГОСТ Р МЭК 60079-18 ГОСТ Р МЭК 60079-31
category: suitable for Zone 1 - 21 (gas) and Zone 2 - 22 (dust)
